Fan Motor Options

Model Tap #

Default

Factory

Motor

Setting

CFM

0.10 0.20 0.30 0.40 0.50 0.60 0.70 0.80 0.90 1.00 1.10 1.20

CL036

1 1205 1178 1158 1130 1104 1075 1050 1020 998 967 877 —

2 1290 1268 1243 1218 1198 1169 1141 1115 1087 1013 918 —

3 X 1398 1376 1348 1329 1301 1283 1256 1222 1146 1045 921 —

4 1503 1481 1451 1434 1412 1378 1320 1250 1149 1043 926 —

5 1752 1696 1645 1585 1529 1451 1376 1294 1198 1087 946 815

CL042

1 1205 1178 1158 1130 1104 1075 1050 1020 998 967 877 —

2 1290 1268 1243 1218 1198 1169 1141 1115 1087 1013 918 —

3 1398 1376 1348 1329 1301 1283 1256 1222 1146 1045 921 —

4 X 1503 1481 1451 1434 1412 1378 1320 1250

1149 1043 926 —

5 1752 1696 1645 1585 1529 1451 1376 1294 1198 1087 946 815

CL048

1 1424 1400 1374 1351 1329 1308 1285 1262 1241 1209 — —

2 1636 1615 1595 1571 1551 1526 1502 1455 1381 1304 — —

3 X 1700 1677 1655 1637 1611 1581 1526 1463 1385 1293 — —

4 1798 1776 1754 1730 1689 1630 1560 1489 1412 1317 — —

5 1889 1865 1827 1777 1718 1652 1579 1499 1412 1328 — —

CL060

1 1851 1818 1792 1758 1729 1698 1660 1627 1588 1539 — —

2 1945 1911 1886 1852 1823 1793 1757 1720 1659 1579 — —

3 X 2026 1994 1965 1938 1901 1874 1825 1760 1683 1593 1487 1370

4 2081 2055 2021 1993 1949 1903 1840 1775

1695 1594 1486 1370

5 2239 2201 2151 2086 2028 1977 1903 1822 1737 1650 1529 1397

CL070

1 2020 1988 1958 1932 1895 1866 1836 1801 — — — —

2 2114 2081 2056 2027 1993 1966 1936 1896 1863 — — —

3 X 2198 2173 2146 2113 2085 2050 2018 1981 1948 1907 — —

4 2334 2303 2272 2245 2215 2181 2148 2103 2046 1972 1886 —

5 2385 2355 2328 2295 2263 2231 2192 2141 2075 1994 1908 1812

Note: Off delay = 30 seconds = After receiving an off command motor will continue running for 30 seconds.

Table 13 Constant Torque Motor Performance Data—Horizontal Configuration

46 |

CL Series Heat Pumps — 8733838716 (2024/05)
