Specification Tables
20.5 Model 24 Thermistor (Freeze Sensor) Test Values
(10,000 ohm at 77°F ±0.36°F from 32°F to 158°F)
Table 22 Model 24 Thermistor (Freeze Sensor) Test Values
Temperature (°F) Resistance
-35 280.1K
-30 324.1K
-25 196.3K
-20 165.1K
-15 139.3K
-10 118.0K
-5 100.2K
0 85.35K
5 72.91K
10 62.48K
15 53.64K
20 46.23K
25 39.91K
30 34.56K
35 30.00K
40 26.10K
45 22.76K
50 19.90K
55 17.44K
60 15.31K
65 13.48K
70 11.88K
75 10.50K
80 9298
85 8250
90 7331
95 6532
100 5826
105 5209
110 4663
115 4182
120 3757
125 3381
130 3047
135 2750
140 2486
145 2251
150 2041
155 1854
160 1686
165 1535
170 1400
175 1278
180 1168
185 1070
190 980.5
195 899.6
200 826.8
205 760.7
210 700.7
215 646.1
220 596.4
225 551.5
230 510.2
235 472.5
240 438.3
Temperature (°F) Resistance
| 71
CL Series Heat Pumps — 8733838716 (2024/05)
