Bosch CL Series User Manual

Dimensional Drawings
22.3 Horizontal (HZ) Unit Dimensions
Table 25 Horizontal (HZ) Units Dimensions
Model CL007 CL009 CL012 CL015 CL018 CL024 CL030 CL036 CL042 CL048 CL060 CL070
Condensate Drain
Connection
3/4" FPT 3/4" FPT 3/4" FPT 3/4" FPT 3/4" FPT 3/4" FPT 3/4" FPT 3/4" FPT 3/4" FPT 3/4" FPT 3/4" FPT 3/4" FPT
Recommended
Replacement Nominal
Filter Size
10" x 16" 10" x 16" 10" x 16" 16" x 24 16" x 24" 17" x 25" 17" x 25" 18" x 30" 18" x 30" 20" x 34" 20" x 34"
20" x 22"
(2 Filters)
Condenser Water
Connections
3/4" FPT 3/4" FPT 3/4" FPT 3/4" FPT 3/4" FPT 3/4" FPT 3/4" FPT 3/4" FPT 3/4" FPT 1" FPT 1" FPT 1" FPT
A
Width
19" 19" 19" 21.5" 21.5" 21.5" 21.5" 21.5" 21.5" 24" 24" 24"
B
Depth
33" 33" 33" 44" 44" 44" 44" 47" 47" 54" 54" 62"
C
Height
11.5" 11.5" 11.5" 17" 17" 18" 18" 19" 19" 21" 21" 21"
D
Discharge
Height
4" 4" 4" 9.75" 9.75" 9.75" 9.75" 11.25" 11.25" 11.25" 12.5" 12.5"
E
Discharge Width
6.5" 6.5" 6.5" 9.25" 9.25" 9.25" 9.25" 10.5" 10.5" 10.5" 11.75" 11.75"
H
Water Inlet
3.75" 3.75" 3.75" 3.25" 3.25" 3.25" 3.25" 3.25" 3.25" 3.25" 3.25" 3.25"
J
Water Outlet
9" 9" 9" 8.5" 8.5" 8.5" 8.5" 8.5" 8.5" 8" 8" 8.5"
M
R/A Duct Width
16" 16" 16" 23.25" 23.25" 24.25" 24.25" 29.25" 29.25" 33.25" 33.25" 43.5"
N
R/A Duct Flange
Height
8.5" 8.5" 8.5" 14" 14" 15.25" 15.25" 16" 16" 18" 18" 18"
P
Filter Rack
Height
11" 11" 11" 16" 16" 17" 17" 18.25 18.25" 20" 20" 20"
R
Cab Front to
Filter Rack
16" 16" 16" 18.5" 18.5" 17.25" 17.25 14.5 14.5" 18" 18" 15"
T
Cabinet End to
Filter Rack
1" 1" 1" .10" .10" .100" .100 1" 1" 1" 1" 1"
U
Side to
Discharge (End)
(Left-Hand
Return)
7.75" 7.75" 7.75" 6" 6" 6" 6" 5.5" 5.5" 5" 5" 5.5"
Side to
Discharge (End)
(Right-Hand
Return)
4.75” 4.75” 4.75” 6” 6” 6” 6” 5.5” 5.5” 5” 5” 5.5”
V
Top to Discharge
(FLE & FRS)
5.87" 5.87" 5.87" 5.75" 5.75" 6.75" 6.75" 6" 6" 8" 6.75" 6.75"
W
End to Discharge
(Straight)
5.5" 5.5" 5.5" 6" 6" 6.5" 6.5" 5.5" 5.5" 5.25" 5" 5.5"
X
Top to Discharge
(FRE & FLS)
1.75" 1.75" 1.75" 1.5" 1.5" 1.5" 1.5" 1.75" 1.75" 1.75" 1.75" 1.75"
• Specifications subject to change without notice.
• All dimensions within ±0.125".
• Overall u
nit dimensions do not include filter rack or duct
flanges.
• Uni
t sizes 015–070 can be field converted between end
blow and straight-through supply air configurations.
92 |
CL Series Heat Pumps — 8733838716 (2024/05)
