Tools Needed for Assembly and Alignment
Combination Square
5mm Hex Key
(supplied)
#2 Phillips Screwdriver
4mm Hex Key
Combination Square Must Be True
Checking Combination Square
1. Position square and
draw a light line
2. Flip square
(shown in dotted position)
3. Check edge of flipped
square against the drawn line.
There should be no gap or
overlap at the bottom end.
drawn line
3/4" board with
straight top edge
no gap or overlap
Assembly
