Bosch Security Systems | 2007-11 | 9922 141 70691 en
DCN Wireless | Installation and User Instructions | Contribution Devices en | 90
17.3 Inst a ll at ion
17.3.1 General
17.3.2 Wall
You can use the bracket to attach the battery charger to
a wall. Refer to figure 17.2.
Warning
Do not open the battery charger. Electrical
discharges from the battery charger can kill you.
Caution
Do not obstruct the ventilation grilles. A block-
age of the ventilation grilles can cause a risk of
fire.
table 17.1: Physical characteristics
Dimensions (h x w x d):
340 x 195 x 82 mm
Weight:
1.4 kg
figure 17.2: Installation, wall
02
03
01
TORX 10
TORX 10
