Bosch Security Systems | 2007-11 | 9922 141 70691 en
DCN Wireless | Installation and User Instructions | Appendices en | 98
A Audio levels
A.1 DCN-WCCU
A.2 DCN-WDU
table A.1: Analog line inputs
Plug or socket Function Nominal Maximum
XLR Floor -12 dBV (- 6, + 6 dB) 12 dBV (- 6, + 6 dB)
Cinch Floor -24 dBV (- 6, + 6 dB) 0 dBV (- 6, + 6 dB)
table A.2: Analog outputs
Plug or socket Function Nominal Maximum
XLR 1 PA -12 dBV(- 24, + 6 dB) 12 dBV (- 24, + 6 dB)
XLR 2 Recorder 9 dBV(- 24, + 6 dB) 12 dBV(- 24, + 6 dB)
XLR 2 Equalized PA 0 dBV(- 24, + 6 dB) 12 dBV (- 24, + 6 dB))
XLR 2 Insertion/ mix-minus -12 dBV(- 24, + 6 dB) 12 dBV (- 24, + 6 dB)
Cinch 1 PA -24 dBV(- 24, + 6 dB) 0 dBV (- 24, + 6 dB)
Cinch 2 Recorder -3dBV(- 24, + 6 dB) 0 dBV (- 24, + 6 dB)
Cinch 2 Equalized PA -12 dBV(- 24, + 6 dB) 0 dBV (- 24, + 6 dB)
Cinch 2 Insertion/ mix-minus -24 dBV(- 24, + 6 dB) 0 dBV (- 24, + 6 dB)
table A.3: Monitor
Plug or socket Function Nominal Maximum
3.5 mm Headphones -1 dBV (mute, - 24 dB, 0 dB) 2 dBV (mute, - 24 dB, 0 dB)
table A.4: Headphones
Plug or socket Function Nominal Maximum
3.5 mm Headphones 3 dBV 6 dBV (mute, 0 dB)
Note
For all other audio levels, refer to the Appendix
in the “DCN Next Generation, Installation &
User Instructions”.
