DCN Wireless | Installation and User Instructions | Appendices en | 99
A.3 DCN-DDI
table A.5: Dual delegate interface
Plug or socket Function Nominal Maximum
8-pole DIN Line in 0 dB
Line in 6 dB
Line in 12 dB
Line in 18 dB
Mic 0 dB
Mic 6 dB
Mic 12 dB
Mic 18 dB
-18 dBV (- 3, + 3 dB)
-12 dBV (- 3, + 3 dB)
-6 dBV (- 3, + 3 dB)
0 dBV (- 3, + 3 dB)
-46 dBV (- 3, + 3 dB)
-40 dBV (- 3, + 3 dB)
-34 dBV (- 3, + 3 dB)
-28 dBV (- 3, + 3 dB)
12 dBV (- 3, + 3 dB)
12 dBV (- 3, + 3 dB)
12 dBV (- 3, + 3 dB)
12 dBV (- 3, + 3 dB)
-16 dBV (- 3, + 3 dB)
-16 dBV (- 3, + 3 dB)
-16 dBV (- 3, + 3 dB)
-16 dBV (- 3, + 3 dB)
3.5 mm --- -5 dBV 7. 5 d B V
