DCN Wireless | Installation and User Instructions | Contribution Devices en | 91
When you attach more than one battery charger to the
wall, you must make sure that:
• The vertical distance between two brackets is at least
340 mm (refer to d1 in figure 17.2).
• The horizontal distance between two brackets is at
least 195 mm (refer to d2 in figure 17.2).
17.3.3 Battery
17.4 External connections
17.4.1 Power inlet
Connect a locally approved power cable to the battery
charger (refer to figure 17.5).
figure 17.3: Installation, multiple battery chargers
d
2
d
1
figure 17.4: Installation, battery
figure 17.5: Power inlet
