Bosch Security Systems | 2007-11 | 9922 141 70691 en
DCN Wireless | Installation and User Instructions | Central Devices en | 55
11.4 Installation
11.4.1 General
11.4.2 Wall or ceiling
You can use the bracket to attach the wireless access
point to a wall or ceiling. Refer to figure 11.2.
Caution
Do not open the wireless access point. Any
hardware change makes the product certificates
invalid. Only qualified personnel can open the
wireless access point.
table 11.1: Physical characteristics
Dimensions (h x w x d):
284.5 x 201.5 x 59 mm
Weight:
• DCN-WAP: 643 g (without bracket)
• Bracket: 264 g
figure 11.2: Installation, wall and ceiling
