PRE INSTALLATION UNIT PREPARATION
Corner Cap Installation Instructions
Each corner cap is stamped with one the following
identifiers: T, T1,T2 B, B1, B2, A.
1. Identify Letter code on each Corner Cap.
(Figure#87)
Figure # 87
2. In preparation for installation identify each
Corner Cap location. (VT & CF Figure#88 and
HZ Figure#89)
Figure # 88
Figure # 89
3. Remove adhesive backing and install each
Corner Cap. (Figure#90 and#91)
Figure # 90
Figure # 91
T
B
A
T2
T1
T1
T1
T2
T2
A
A
A
A
Ensure cabinet surface is clean and free of
debris to ensure proper Corner Cap Adhesion.
To Next Page
