Troubleshooting | 33Greensource CDi Series TW Model
8733954853 (2020/04)Greensource CDi Series TW Model
Subject to change without prior notice
Unit Lockouts
Periodic lockouts almost always are caused by
water flow problems. The lockout (shutdown) of
the unit is a normal protective measure in the
design of the equipment. If continual lockouts
occur call a mechanic immediately and have them
check for: water flow problems, water
temperature problems. Use of the pressure and
temperature charts for the unit may be required to
properly determine the cause.
Electric Data Table
Table 11 Electric data table
UPM LED Status Indicator (Blink Code)
Information
The LED status indicator is found on the UPM
boards. See Fig. 9 on page #16 for the UPM Board.
Table 12 UPM LED Status Indications
See Fig. 11 on page #19 for the UPM II Board.
Table 13 UPM I I LED Status Indications
Models
Voltage
Code
Rated
Voltage
Voltage
Min/
Max
Compressor
QTY RLA LRA
Min
Circuit
Amps
Max
Fuse/
HACR
TW025
1
208–230/
60/1
197/253
1 11.7 58.3 14.6 25
TW035
1
208–230/
60/1
197/253
1 15.6 83.0 19.5 35
TW049
1
208–230/
60/1
197/253
1 21.2 104.0 26.4 45
TW061
1
208–230/
60/1
197/253
1 26.9 139.0 33.6 60
TW122
1
208–230/
60/1
197/253
2 26.9 139.0 60.5 80
Indication
Color
Blinks Description
GREEN Solid 18–30 VAC power is present
RED 1 High-pressure lockout
RED 2 Low-pressure lockout
RED 3 Freeze 1 sensor lockout
RED 4 Condensate overflow
RED 5 Brownout
RED 6 Freeze 2 sensor lockout
Indication
Color
Blinks Description
GREEN Solid 18–30 VAC power is present
RED 1 High-pressure lockout —
Circuit 1
RED 2 Low-pressure lockout —
Circuit 1
RED 3 High-pressure lockout —
Circuit 2
RED 4 Low-pressure lockout —
Circuit 2
RED 5 Freeze sensor lockout
RED 6 Condensate overflow
RED 7 Brownout
