-32-
Storage, Transportation, and Mounting
Mounting the Table Saw
(Fig. 37, Fig. 38)
To prevent personal injury,
always disconnect the Bat-
tery Pack before mounting the saw.
To prevent movement while cutting, the table
saw must be fastened securely to a stand or
workbench, using the four Mounting Holes 35.
If mounting the saw to a workbench, the Base
5 should be secured using four 3-1/2” (89 mm)
long screws (not included) through the Mount-
ing Holes 35. Make sure the screws extend
through the saw’s frame and securely attach
into the supporting work surface.
35
35
35
rear of saw
Fig. 38
35
35
35
front of saw
5
Fig. 37
