R320103169/2020-08 | Linear modules MKK/MKR-xxx-NN-3 Bosch Rexroth AG 41/62
Guideway: Lubrication point 1 (a/b) BASA: Lubrication point 2 (a/b)
Lubricant quantity (cm
3
) doxP Lubricant quantity (cm
3
)
LPG LCF LCO (mm) LPG LCF LCO
TM1 TM2 TM1 TM2
MKK-040 1.00 0.30 1.00 0.80
12x2 0.67 0.12
0.50 1.2012x5 0.77 0.22
12x10 0.77 0.22
MKK-065 1.70 0.80 1.10 2.10
16x5 1.10 0.60
0.50 0.6316x10 1.15 0.65
16x16 1.30 0.80
MKK-080 3.00 1.40 1.80 3.50
20x5 1.40 0.70
0.90 1.0620x10 1.70 1.00
20x20 2.70 1.60
20x40 1.90 1.20 1.00 1.26
MKK-110 4.50 2.80 1.90 4.15
32x5 2.80 1.50
1.30 1.26
32x10 3.40 2.10
32x20 3.70 2.40
32x32 4.90 3.60
MKK-140 6.40 4.40 8.00 14.00
40x5 4.20 2.00
3.00 2.50
40x10 4.80 2.60
40x20 5.10 2.90
40x40 12.00 9.80
Table 9: Initial lubrication quantity MKK-NN-3
Table 10: Initial lubrication quantity MKR-NN-3
Guideway: Lubrication point 1, 3 (a/b)
Lubrication quantity short carriage (cm
3
) Lubrication quantity long carriage (cm
3
)
LPG LCF LCO LPG LCF LCO
TM1 TM2 TM1 TM2
MKR-040 – – – – 1.00 0.30 0.30 0.60
MKR-065 – – – – 1.45 0.80 1.60 1.80
MKR-080 1.60 0.70 1.40 1.90 2.60 1.40 2.80 3.00
MKR-110 3.00 1.40 2.80 2.80 4.10 2.80 5.60 3.70
MKR-140 – – – – 6.40 0.30 5.60 12.00
MKR-145 – – – – 9.0
1)
2.80
1)
5.60
1)
3.60
1)
