2.3.3 Sensor supplies and screens
4 x sensor supplies 5 V / 50 mA
3 x sensor supplies 5 V / 150 mA
7 x sensor grounds
2 x sensor screens
2.3.4 Outputs
19 freely configurable outputs in a mix of different hardware designs
8 x 2.2 amp pwm lowside switch
4 x 3 amp pwm lowside switch
2 x 4 amp pwm lowside switch
2 x 1 amp pwm lowside switch
2 x 1 amp pwm lowside switch, low dump resistant
1 x 8.5 amp H-bridge
38 function related outputs
12 x ignition controls, support of coils with integrated amplifier only
12 x low pressure injection power stages for high impedance valves
(max. 2.2 amps and min. 6 Ohm internal resistance of the injectors)
8 x high pressure injection power stages for magnetic valves (HDEV 5)
2 x outputs for high pressure pump controls (MSV)
2 x 8.5 amp H-bridge for electronic throttle control
2 x 4 amp pwm lowside switch for Lambda heater
3 output signals
1 x flywheel
1 x trigger wheel
1 x engine rpm
