Bosch MS 6 - Creating New CAN Output Channels

CAN Configuration | 7
Bosch Motorsport Engine_Control_Unit_MS_6.x_Manual 65/76
The ‘New CAN-OUT message’ window opens.
2. Enter name of message, description, CAN-Id and Grid (output interval).
Optionally, specify a multiplexer.
Definition of
CAN message
Content of
message
3. Click on ‘Add channel’ or ‘Add constant’, this opens the ‘Add new CAN out channel’
window.
4. Select the desired measurement channel and specify the message settings.
Click here
The measurement channel is now assigned to the CAN message.
