Pack201 | Operator Interface | Section 4
EN | 49
© Bosch Packaging Technology, Inc.
All rights reserved 2012
PARAMETER DEFINITION
Out Of Registration # To Reject (prod) This is the desired number of packages to reject when an out of registra-
tion package is detected�
Out Of Registration Reject Enable In the ON position the out of registration reject is active� In the OFF
position the reject is disabled�
Out Of Registration Reject Shifts (prod) This is the number of cycles from the out of registration reject eye to the
reject device�
Package Length (mm) This is the measured distance between two registration marks on the
sealing material�
Pause Offset (deg) This is a correction that may be added to change the position of the cut-
ting head pause�
Power Feed Roll Enable In the ON position the power feed roll motor is active� In the OFF posi-
tion the motor is disabled�
Product Length This is the actual measured length of the product to be run�
Product Offset (Position) (mm) This is the position of the product in the package� This value can be
adjusted�
Product Width (mm) This is the actual measured width of the product to be run�
Products Per Flight This is the actual number of products to be in each infeed ight.
Pulse X Enable In the ON position the pulse is active� In the OFF position the pulse is
disabled�
Pulse X Speed Compensation This allows for mechinacal delays at higher speeds to keep the pulse X
“window” in position�
Rate At 10 Volts This is the speed that the machine will run with a 10 volt signal from the
feeder�
Registration Enable In the ON position the registration eye is active� In the OFF position the
registration eye is disabled�
Registration Offset (Cut Position) This is the position of the cutoff on a package when running registered
lm.
Reject Verify Shift (cycles) This is the number of cycles from the reject verify eye to the reject de-
vice�
Remote Feeder Enable In the ON position the remote feeder option is active� In the OFF posi-
tion the option is disabled�
Remote Speed Inc/Dec This function has not yet been developed�
Run Rate (ppm) This is the desired wrapper speed in packages per minute when the
machine is in run mode�
Short Product # To Reject This is the desired number of packages to reject when a short product
is detected�
Short Product Reject Enable In the ON position the short product reject eye is active� In the OFF
position the reject eye is disabled�
Short Product Reject Shifts This is the number of cycles from the short product reject eye to the
reject device�
Short Sync Cycles This is the number of cycles the machine will run during the short sync
operation� (Typically the number of packages from the endseal crimpers
to the pusher drop off�)
