Pack201 | Operator Interface | Section 4
EN | 50
© Bosch Packaging Technology, Inc.
All rights reserved 2012
PARAMETER DEFINITION
Side Chain Offset This is a correction that may be added to change the position of the side
chain pushers�
Side Chain Pitches This is the number of pitches between every two side chain pushers�
Side Chains Enable In the ON position the side chain option is active� In the OFF position
the option is disabled�
Speed Eye Acceleration Gain This is the time required for the wrapper to go from a stopped position
to 600 packages per minute�
Speed Eye Deceleration Gain This is the time required for the wrapper to go from 600 packages per
minute to a stopped position�
Speed Eye Off Delay (mm) This is a delay added to prevent the wrapper from going to low speed as
soon as the Speed eye is unblocked�
Speed Eye On Delay (mm) This is a delay added to prevent the wrapper from going to run speed as
soon as the Speed eye is blocked�
Speed Ref� At 10V This is the wrapper speed that will equal 10 volts DC sent out to exter-
nal equipment�
Splice # To Reject (prod) This is the desired number of packages to reject when a splice is pro-
duced�
Splice Reject Enable In the ON position the splice reject eye is active� In the OFF position the
reject eye is disabled�
Splicer Enable In the ON position the splicer option is active� In the OFF position the
option is disabled�
Splicer Offset This is a correction that may be added to change the position of the
splice�
Splicer Reject Shifts This is the number of cycles (packages)from the splicer to the reject
device�
Splicer Shifts This is the number of cycles (packages) from the splicer eye to the
splicer rollers�
Static Seal Enable In the ON position the static seal option is active� In the OFF position
the option is disabled�
Stop Delay Angle deg) This is the position in a cycle where the machine starts to decelerate
after the stop button is pushed�
Stop Rate This is the desired wrapper speed in packages per minute for the wrap-
per to come to a position stop�
Sweep Base Rate This sets the base speed of the overhead sweep� A value of 100% means
that the sweep would run at a steady speed�
Sweep Offset This is a value that can be added to change the placement of the prod-
uct in the infeed conveyor ight.
Sweep Pitches This is the number of inches between overhead sweep chain pushers
times 2�
Sweep Prole Begin/End This is the point during a machine cycle at which the overhead sweep
starts to speed up� The sweep will return to base rate at the same value
short of the end of the cycle�
Sweep Ratio This is the ratio of the LPF secondary chain ights to the wrapper infeed
chain ights.
