Pack201 | Functional Descriptions | Section 5
© Bosch Packaging Technology Inc.
All rights reserved 2012
EN | 7
5.6 Discharge Conveyor
The discharge conveyor is located directly
after the endseal� It has a drive motor and
roller assembly, two nose roller assemblies,
and a belt� This conveyor is designed to be
easily removed from the wrapper�
There is adjusment hardware to tension and
properly track the belt�
Tracking Screws
and Jam Nuts
Tension Adjust Bolts
