RADION receiver SD Table of contents | en 3
Bosch Security Systems B.V. 2020.05 | 13 | F.01U.261.834
Table of contents
1
Introduction 6
1.1 About documentation 7
1.2 Bosch Security Systems, Inc. product manufacturing
dates
7
2
General installation 8
2.1 Installation workflow 9
2.2 Unpacking information 9
2.3 Wall tamper switch installation 10
2.4 Magnet cover installation 11
2.5 Complete installation 11
2.6 Maintenance 11
3
RADION receiver SD 13
3.1 Check-in interval and power level for RADION devices 13
3.2 Certifications and approvals 14
3.3 UL product requirements 18
3.4 Installation 22
3.4.1 Configuration 22
3.4.2 Base installation 24
3.4.3 Wiring considerations 25
3.4.4 Programming wireless points in the control panel 26
3.4.5 Enroll point RF ID for wireless points (Auto-learn mode) 29
3.4.6 Walk test (for motion detectors) 30
3.4.7 Signal level and margin 31
3.4.8 Complete the installation 33
3.4.9 B810 system test 33
3.5 External LED states 33
3.5.1 LEDs 35
3.6 Specifications 37
3.6.1 Battery requirements 37
4
RADION repeater 41
4.1 Installation considerations 42
4.2 Wiring considerations 42
4.3 Specifications 42
4.4 LEDs 44
