RADION receiver SD RADION TriTech | en 53
Bosch Security Systems B.V. 2020.05 | 13 | F.01U.261.834
Battery replacement Duracell MN1500, Panasonic AM-3PIX.
Check your battery yearly to ensure
proper functionality.
Battery life Up to 5 years
Device testing To ensure proper functionality, the
device must be tested at least once
every year by an installer.
Wall and cover tamper
switch
Transmits a tamper signal when
someone removes the device from its
base or pulls it away from the wall.
Frequency 433.42 MHz
Table6.7: Specifications
6.1 Mounting height and range adjustment
Loosen the vertical adjustment screw. Adjust the board to the
desired angle. Choose mounting height and desired range, and
set the vertical angle. Reference the table below for proper
height and adjustment values.
Mounting height Range
6.1 m (20 ft) 10.7 m (35 ft)
2 m (6.5 ft) -7ﾟ -5ﾟ
2.1 m (7.0 ft) -9ﾟ -6ﾟ
2.4 m (8.0 ft) -10ﾟ -7ﾟ
Tab.6.8: Mounting height
Notice!
The mounting height must be 2 m (6.5 ft) and the vertical angle
must be set at -5ﾟ for installations containing pets.
