RADION receiver SD RADION specialty | en 79
Bosch Security Systems B.V. 2020.05 | 13 | F.01U.261.834
15.2 Installation consideration
During the installation process, use the self-adhesive Velcro
strips located on the bottom of the bill trap base, to secure and
stabilize the bill trap in the cash drawer. This is achieved by
performing the following:
1. Separate the Velcro strips from one another.
2. Peel off the protective backing of the Velcro strips.
3. Press the two bottom sections of the Velcro onto the
bottom of the cash drawer, in the desired location.
4. Line up and press down on the bill trap so that the Velcro
on the bottom of the bill trap is aligned with the Velcro
strips inside the cash drawer.
Warning!
It is important to check the Velcro strips on a weekly basis for
wear and replace when appropriate in order to prevent
potential false alarms.
