14.1 Installation considerations
You have a variety of installation options to consider when
installing the device. You must acknowledge the unique
installation approach prior to installation. Some installation
considerations include:
– The installation of this device is suitable for wood surfaces.
This device is not suitable for steel surfaces.
– The transmitter housing was designed to be open with a
coin. Using a screwdriver may cause damage to the plastic
top.
– When reinserting the PCB (battery and antenna assembly),
verify that the PCB assembly fits into the grooves of the
transmitter housing.
– When reinserting the plastic top, verify that the top fits into
the designed grooves of the transmitter housing.
– When installing the transmitter in an overhead location, be
mindful that the PCB assembly may fall out of the
transmitter housing.
– The removal of the plastic flaps is optional, depending on
your installation needs.
– For added security, you can use an adhesive with the
screws to secure the transmitters and magnets.
Notice!
EN requirements
For further information regarding certified installations, please
refer to EN product requirements.
How to read the Graphical Magnet Distances table
Contained in the recessed door/window contact Installation
Guide is a graphical table along with the X ￚ Y coordinates
graphic. Use the table in conjunction with the graphic to
determine desired distances between the magnet and the
transmitter based on the type of installation.
