Scope ofdelivery 17/60
RE 92801-01-B/11.2018, A15VSO/A15VLO Series 11, BoschRexrothAG
4 Scope ofdelivery
5
3
4
4
1
2
or
Fig. 1: Axial piston unit
Included inthe scope ofdelivery:
• Axial piston unit asper order confirmation
The following parts come assembled onthe unit:
• Protective cover incl. mounting bolts(1)
• Threaded plug(2)
• Protective plug (3)
• Steel flange covers (the flange cover onthe suction port provides asecure stand
and protection for the V
gmax
stop) (4)
• for version with through drive, protective cover incl. mounting bolts(5)
