28 A6VM series 71 | Axial piston variable motor
Dimensions size 60
Dimensions [inch (mm)]
▼ EP1, EP2 – Electric proportional control,
positive control
▼ EP5D1, EP6D1 – Electric proportional control,
negative control, with pressure control, fixed setting
M
1
B A
10.35 (263)
8.86 (225)
4.21 (107)
G
G
M
1
M
1
M
1
G
B A
G
6.06 (154)
6.93 (176)
10.51 (267)
▼ HP1, HP2 – Hydraulic proportional control,
positive control
▼ HP5, HP6 – Hydraulic proportional control,
negative control
M
1
X
G
X
G
1.40
(35.5)
7.24 (184)
10.35 (263)
B A
6.26 (159)
4.21 (107)
5.47 (139)
M
1
X
G
X
G
9.21 (234)
10.39 (264)
6.06 (154)
3.54 (90)
4.33 (110)
B A
1.40
(35.5)
M
1
M
1
▼ HP5D1, HP6D1 – Hydraulic proportional control,
negative control, with pressure control, fixed setting
1.40
(35.5)
9.41 (239)
10.39 (264)
M
1
G
G X
X
M
1
B A
6.06 (154)
3.50 (89)
4.72 (120)
