Bosch Rexroth A6VM series 71 - Size 60: Additional Control Variant Dimensions; Size 60 HZ7 Hydraulic Two-Point Control Dimensions; Size 60 EZ7;EZ8 Electric Two-Point Control Dimensions

RE-A 91610/12.2015, Bosch Rexroth Corp.
Axial piston variable motor | A6VM series 71
Dimensions size 60
29
Dimensions [inch (mm)]
▼ HZ7 – Hydraulic two-point control,
negative control
▼ EZ7, EZ8 – Electric two-point control,
negative control
2.40
(61)
G
X
AB
0.94 (24)
1.22 (31)
1)
5.75 (146)
4.61 (117)
G
6.89 (175)
9.41 (239)
1)
X
8.15 (207)
9.88 (251)
3.94 (100)
4.88 (124)
G
AB
G
9.41 (239)
1)
0.94 (24)
1.22 (31)
1)
5.75 (146)
8.15 (207)
9.88 (251)
3.94 (100)
▼ HA1, HA2 / HA1T3, HA2T3 – Automatic high-pressure-related
control, positive control, with override hydraulic remote con-
trolled, proportional
▼ HA1U1, HA2U2 – Automatic high-pressure-related control,
positive control, with override, electric, two-point
X
G
X
G
1.40
(35.5)
7.24 (184)
10.35 (263)
B A
6.26 (159)
4.21 (107)
5.47 (139)
M
1
M
1
B A
8.86 (225)
G
G
10.35 (263)
4.21 (107)
M
1
M
1
HA1 and HA2, X plugged
HA1T and HA2T, X open
▼ HA1R1, HA2R2 –
Automatic high-pressure-related control, positive
control, with override, electric and travel direction valve, electric
a
b
G
G
B A
4.33
(110)
10.35 (263)
8.86 (225)
4.21 (107)
M
1
M
1
1) Port plate 1 – SAE working ports A and B at rear
