Digital Inputs (Safety Technology S Options)
The digital inputs correspond to IEC 61131, type 1.
Data Unit Min. Max.
Allowed input voltage V -3 30
High V 15 30
Low V -3 5
Current consumption mA 2 5
Tab. 8-30: Digital Inputs (Safety Technology S Options)
Bosch Rexroth AG DOK-INDRV*-CXX02******-PR03-EN-P118/143
IndraDrive Control Sections CSB02, CSE02, CSH02, CDB02
Technical data - functions
