5.5.2 CSB02.5 type code
Short type designation 1 2 3 4 5 6 7 8 9
1
0 1 2 3 4 5 6 7 8 9
2
0 1 2 3 4 5 6 7 8 9
3
0 1 2 3 4 5 6 7 8 9
4
0
Example: C S B 0 2 . 5 B - E T - E C - P B - L 3 - E C - N N - F W
① ② ③④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪
① Product:
CSB = Single-axis control section BASIC
② Series:
02 = 02
③ Design:
5 = For Hxx05
④ Interface equipment:
B = Extended scope
⑤ Communication:
ET = Multi-Ethernet
⑥ Interface 1:
EC = Multi-encoder interface
⑦ Interface 2:
NN = Not equipped
PB = PROFIBUS
CN = CANopen
EC = Multi-encoder interface
EM = Encoder emulation
⑧
Interface 3 (safety technology)
1)
:
NN = Not equipped
L3 = STO (Safe Torque Off)
S4 = Safe Motion
S5 = Safe Motion
SB = Safe Motion Bus
⑨ Interface 4:
NN = Not equipped
EC = Multi-encoder interface
2)
EM = Encoder emulation
3)
DA = Digital/analog I/O extension
⑩ Other design:
NN = None
⑪ Firmware:
FW = Firmware must be ordered as a separate subposition
NW = Without control panel, without firmware
1) The L3, S4, S5 and SB interfaces guarantee both the function
and the certification
