Bosch VPV 16 - Page 41

40 VPV Vane Pump
VPV 100/130/164, Single pump, S.A.E. ‘D’ flange, RH rotation (continued)
{|
BOSCH
OUT
IN
{
BOSCH
BOSCH
|
|
6.09
(154.7)
3.76
(95.7)
9.82
(249.4)
4.15
(105.5)
9.24
(234.7)
7.65
(194.2)
17.00
(432.0)
8.57
(217.7)
max.
13.95
(354.5)
Optional volume control
(CW rotation reduces flow)
Lift point
M10 x 1.5 - 6H x 11.0 deep th'd
6.20
(157.4)
12.90
(327.8)
12.00
(304.8)
1.82
(46.3)
1.41
(35.9)
0.70
(17.9)
2.75
(69.9)
1.37
(34.9)
Std S.A.E. 1-1/2"
pad pressure
1.46
dia.
(37.1)
2.96
(75.1)
0.49
(12.4)
0.32
(8.1)
1/2” – 13 UNC, 28 deep,
4 holes
Pump control
mounting
datum "T"
Pump centerline
Pump centerline
Optional combination capable pump
with end cover (P1 Version)
Inches (millimeters)
