Bosch VPV 16 - VPV 100;130;164 to VPV 100;130;164 S.A.E. & Metric Combination, Installation Drawing

62 VPV Vane Pump
VPV 100/130/164 to VPV 100/130/164, S.A.E. & Metric Combination
,y
,yz
z
,y
,yz
z
z
,y
{
{|
|
,y
,y
,y
,y
,yz
z
,y
,yz
z
3.82
(97.0)
4.24
(107.8 )
3.89
(99.0)
2.78
(70.8)
4.70
(119.4)
1.67
(42.5)
1.65
(42.0)
2.66
(67.7)
Optional 2 pressure
solenoid operated vent
compensator
Optional 2 pressure
solenoid operated
compensator
Manual override
pushpin
1/2" conduit
connector
DIN 43650 connector
w/ 1/2" NPT compression
fitting and sentinal light
(Optional)
Optional 2 stage with
load sense compensator
Load sense port
"S.A.E." #4 SAE
"Metric" 1/4-19 BSPP
0.70
(18.0)
1.85
(46.9)
45°
12.80
(325.0)
12.80
(325.0)
ø7.87
(ø200.0)
METRIC 4-bolt
mounting flange
per ISO 3019/2
ø1.57
(ø40.0)
.47
square key
(12.0)
.44
square key
(11.1)
.81
(20.7)
ø1.75
(ø44.42)
S.A.E. “D” 2-bolt
mounting flange
per ISO 3019/1
9.00
(229.0)
1.94
(49.3)
DETAIL SAE-SAE
DETAIL METRIC-METRIC
Compensator adjusting knob
(CW rotation increases
pressure setting)
1.91
(48.6)
2 stage
compensator
Remote control port
1/19-20 BSPP, 0.48/ (12.2) deep
Compensator adjusting knob
(CW rotation increases
pressure setting)
1.91
(48.6)
2 stage
compensator
Remote control port
7/16 – 20 UNF, 0.45/ (11.4) deep
Inches (millimeters)
