Bosch VPV 16 - Page 64

VPV Vane Pump 63
VPV 100/130/164 to VPV 100/130/164 (continued)
IN
OUT
IN
OUT
,y
T
,y
T
D
12.11
(307.6)
6.06
(153.8)
22.60
(574.0)
28.36
(720.3)
6.75
(171.5)
5.77
(146.6)
4.72
(120.0)
13.97
(354.9)
19.07
(484.4)
21.55
(547.4)
Optional 2 pressure
solenoid operated (and vent)
compensator
Remote control port
ø.69 thru support hole
(ø17.5)
Case drain
“SAE” #8 S.A.E.
typ
“METRIC” 3/8-19 BSPP
3.77
typ
(95.7)
2.24
(57.0)
0.95
(24.0)
Inlet port
Std. S.A.E. 2 1/2” pad
ø2.47
typ
(ø62.7)
4.39
(111.6)
typ
3.50
(88.9)
typ
1.75
(44.5)
typ
2.00
(50.8)
typ
1.00
(25.4)
typ
“SAE” 1/2-13UNC-2B TH’D
X
1.10
deep
“METRIC” M12 X 1.75-6H TH’D (28.0)
Support point
“SAE” 5/8”-11UNC-2B TH’D
X
1.30
deep
“METRIC” M16 X 2-6H TH’D (33.0)
Compensator adjusting knob
(CW rotation increases
pressure setting)
SAE/METRIC
SAE/METRIC
A
B
A
B
(SH.2 A K-3)
(SH.2 @ C-6)
8.85
(224.7)
10.40
(264.2)
9.36
(237.8)
11.09
(281.7)
Inches (millimeters)
