Bosch VPV 16 - VPV 32;16, Combination Pump, S.A.E. B Flange, RH Rotation, Installation Drawing

VPV Vane Pump 45
VPV 32/16, Combination pump, S.A.E. ‘B’ flange, RH rotation


z
|
|
{
BOSCH
OUT
IN
,

y
{
{
|
IN
OUT
IN
OUT
{
z|
BOSCH
{
BOSCH
OUT
IN
{
{
{
VIEW B-B VIEW A-A
3.33
(84.6)
2.61
(66.4)
0.4
(10.2)
Optional volume control
(CW rotation reduces flow)
ø0.47
thru, support holes
(ø12.0)
Optional vertical supports
for combination pumps
when rotated 90°
Outlet port,
#12 S.A.E.
Support (Lift) point
3/8"-16UNC-2B X 22.0mm deep
Inlet port,
#16 S.A.E.
Case drain port,
#8 S.A.E.
Inlet port,
#24 S.A.E.
Case drain port,
#8 S.A.E.
Support (Lift) point
3/8"-16UNC-2B X 22.0mm deep
1.08
(27.5)
1.08
(27.5)
4.65
(118.0)
8.14
(206.8)
1.36
(34.5)
1.36
(34.5)
10.62
(269.7)
8.79
(223.3)
4.95
(125.8)
4.18
(106.2)
11.44
(290.7)
9.90
(251.5)
5.44
(138.2)
4.65
(118.1)
Optional 2-stage
compensator (now
in modular design)
2-stage compensator
adjusting knob
(CW rotation increases
pressure rating)
Compensator
adjusting knob
(CW rotation increases
pressure rating)
Standard single
stage compensator
4.65
(118.0)
8.14
(206.8)
5.53
(140.5)
12.79
(324.9)
10.27
(260.9)
7.81
(198.3)
4.58
(116.4)
Remote control
port, #4 S.A.E.
6.63
(168.6)
3.86
(98.0)
12.06
(306.4)
14.92
(379.0)
13.37
(339.7)
5.24
(133.3)
A
A
B
B
2.35
(59.7)
7.06
(179.4)
3.53
(89.7)
3.35
(85.0)
11.55
(293.4)
12.10
(306.9)
3.86
(98.0)
.56
(14.2)
.36
(9.25)
6.63
(168.6)
5.26
(133.7)
max.
.31
(7.8)
10.27
(260.9)
7.81
(198.3)
1.57
(40.0)
Outlet port,
#16 S.A.E.
ø4.00
(ø101.6)
5.75
(146.0)
S.A.E. "B" 2-bolt
mounting flange
.56
(14.4)
.98
(25.0)
25
square key
(6.35)
ø.87
(ø22.2)
shaft dia.
Key & Shaft Detail
1.57
(40.0)
5.61
(142.5)
4.11
(104.5)
2.80
(71.3)
#6 S.A.E.
Shock clipper port.
Should be plumbed
to tank to activate
shock clipper function
(See page 97).
4.81
(122.3)
max
#6 S.A.E.
Shock clipper port.
Should be plumbed
to tank to activate
shock clipper function
(See page 97).
Inches (millimeters)
