Bosch VPV 16 - VPV 45;63;80 to VPV 16, S.A.E. & Metric Combination, Installation Drawing

VPV Vane Pump 47
VPV 45/63/80 to VPV 16, S.A.E. & Metric Combination
{|
|
,yz
,y
IN
OUT
,y
IN
OUT
,y
,y
ø6.30
(ø160.0)
9.31
(236.5)
6.61
(168.0)
7.44
(189.0)
0.55
(14.0)
45° typ
METRIC 4-bolt
mounting flange
per ISO 3019/2
Optional eye bolt
Single stage compensator
Compensator
adjusting knob
(CW rotation
increases pressure
setting)
5.91
(150.0)
1.45
(36.9)
ø1.26
(ø32.0)
0.39 X 0.31
rectangular key
(10.0 X 8.0)
1.39
(35.23)
ø1.25
(ø31.74)
0.31
square key
(7.98)
9.31
(236.5)
5.91
(150.0)
5.96
(151.4)
13.03
(330.8)
7.13
(181.0)
18.27
(464.1)
14.90
(378.5)
3.89
(98.9)
4.37
(111.0)
10.12
(257.2)
4.37
(111.0)
7.44
(189.0)
3.44
(87.5)
2.81
(71.3)
2.81
(71.3)
.76
(19.2)
1.53
(38.89)
Inlet port
std. SAE 2” pad
ø2.00
(ø50.8)
3.06
(77.78)
0.84
(21.44)
2.04
(51.7)
1.69
(42.88)
4.00
(101.5)
Case drain port
“METRIC” 3/8-19 BSPP
“SAE” #8 S.A.E.
SAE “C” 2-bolt
mounting flange
per ISO 3019/1
.69
(17.6)
5.96
(151.4)
13.03
(330.8)
DETAIL SAE-SAE DETAIL METRIC-METRIC
2.08
(52.8)
2.08
(52.8)
16.80
(426.8)
10.50
(266.8)
13.62
(346.0)
ø.47
thru support hole
(ø12.0)
16.14
(410.0)
Inlet port
“SAE” #16 S.A.E.
“METRIC” 1-11 BSPP
Case drain port
“SAE” #8 S.A.E.
“METRIC” 3/8-19 BSPP
Support point
“SAE” 3/8"-16UNC-2B TH’D
X
.59 deep
“METRIC” M10 X 1.5-6H TH’D (15.0)
“SAE” 1/2"-13UNC-2B TH’D
X
1.14 deep typ
“METRIC” M12 X 1.75-6H TH’D (29.0)
4 holes
SAE/METRIC SAE/METRIC
A
B
A
B
(SH.2 @ K-3)
(SH.2 @ D-6)
4.94
(125.4)
SINGLE STAGE CONTROL
NOT AVAILABLE ON VPV 45-164
Inches (millimeters)
