Bosch VPV 16 - Page 49

48 VPV Vane Pump
VPV 45/63/80 to VPV 16 (continued)
|
X
T
BOSCH
2
1 0 9
8
BKS
BOSCH
,y
,y
BOSCH
OUT
IN
ø4.92
(ø124.97)
.36
(9.25)
.41
(10.5)
2.70
(68.5)
ø5.00
(ø126.98)
.31
(8.0)
2.04
(51.7)
.49
(12.45)
2.20
(56.0)
Detail SAE1
Detail METRIC1
Optional VPV25/32 single stage
compensator with locking device
Shock clipper drain
"SAE" #6 S.A.E.
"ISO" 3/8-19 BSPP
.94
(23.8)
6.50
(165.1)
6.89
(174.9)
max.
See detail “SAE1/METRIC1”
“SAE” 7/16-14UNC-2B TH’D
X
1.14
deep typ
“METRIC” M12 X 1.75-6H TH’D (29.0)
4 holes
1.16
(29.36)
2.31
(58.72)
.59
(15.09)
1.19
(30.18)
5.36
(136.2)
13.62
(346.0)
10.50
(266.8)
Outlet port
Std. SAE 1-1/4" pad
ø1.25
(ø31.8)
Suport (Lift) point
“SAE & METRIC” M10 X 1.5 - 6H TH’D
X
..44
deep
(11.2)
Suport point
“SAE" 3/8" - 16 UNC - 2B TH’D
X
.59
deep
(15.0)
“METRIC” M10 X 1.5-6H TH’D
X
.59
deep
(15.0)
Optional
volume control
(CW rotation
reduces flow)
3.84
(97.6)
4.81
max
(122.3)
2.95
(75.0)
1.35
(34.4)
8.87
(225.4)
5.00
(127.1)
4.21
(106.9)
Outlet port
“SAE” #12 S.A.E.
“METRIC” 1/-14 BSPP
VIEW A-A
(SH.1 @ N-4)
VIEW B-B
(SH.1 @ H-2)
Inches (millimeters)
