Bosch VPV 16 - VPV 45;63;80 to an G Gear Pump, S.A.E. & Metric Combination, Installation Drawing

56 VPV Vane Pump
VPV 45/63/80 to an ‘G’ Gear pump, S.A.E. & Metric Combination
z
,y
IN
OUT
,y
,yz
z
z
ø6.30
(ø160.0)
9.31
(236.5)
0.55
(14.0)
45° typ
METRIC 4-bolt
mounting flange
per ISO 3019/2
5.91
(150.0)
1.37
(34.9)
ø1.26
(ø32.0)
0.39 X 0.31
rectangular key
(10.0 X 8.0)
1.39
(35.23)
ø1.25
(ø31.74)
0.31
square key
(7.98)
9.31
(236.5)
5.91
(150.0)
5.96
(151.4)
13.03
(330.9)
7.13
(181.0)
D
3.89
(98.9)
4.37
(111.0)
8.74
(222.0)
5.76
(146.2)
10.13
(257.2)
.76
(19.2)
1.53
(38.89)
Suction
Inlet port
std. SAE 2" pad
ø2.00
(ø50.8)
3.06
(77.78)
0.84
(21.44)
2.04
(51.7)
1.69
(42.88)
4.00
(101.5)
7.30
(185.5)
8.00
(203.1)
4.31
(110.0)
Case drain port
"METRIC" 3/8-19 BSPP
"SAE" #8 S.A.E.
SAE "C" 2-bolt
mounting flange
per ISO 3019/1
.69
(17.6)
5.96
(151.4)
13.03
(330.8)
DETAIL SAE-SAE DETAIL METRIC-METRIC
2.08
(52.8)
2.08
(52.8)
C
A
B
10.50
(266.7)
ø.47
thru support hole
(ø12.0)
Support point
"SAE" 3/8"-16UNC-2B TH'D
X
.87 deep
"METRIC" M10 X 1.5 6H TH'D (22.0)
"SAE" 1/2"-13UNC-2B TH'D
X
1.14 deep typ
"METRIC" M12 X 1.75-6H TH'D (29.0)
4 holes
SAE/METRIC SAE/METRIC
A
B
A
B
(SH.2 K-6)
(SH.2 D-6)
4.94
(125.4)
4.19
(106.4)
Inlet:
1.031
(26.2)
Outlet:
0.875
(22.2)
Inlet:
2.062
(52.3)
Outlet:
1.875
(47.6)
Compensator
adjusting knob
(CW rotation
increases
pressure
setting)
Optional
2 stage compensator
Optional
eye bolt
1.91
(48.6)
Standard
2 stage compensator
Rotation arrows
cast into body
Compensator adjusting knob
(CW rotation increases
pressure setting)
Remote control port
7/16 – 20 UNF, 0.45/(11.4) deep
6.61
(168.0)
7.44
(189.0)
Inches (millimeters)
