Bosch VPV 16 - Page 56

VPV Vane Pump 55
VPV 45/63/80 to an ‘F’ Gear pump (continued)
,y
IN
OUT
z
ø6.30
(ø160.0)
9.31
(236.5)
0.55
(14.0)
45° typ
METRIC 4-bolt
mounting flange
per ISO 3019/2
5.91
(150.0)
1.37
(34.9)
ø1.26
(ø32.0)
0.39 X 0.31
rectangular key
(10.0 X 8.0)
G
4.37
(111.0)
8.74
(222.0)
5.76
(146.2)
10.13
(257.2)
5.96
(151.4)
13.03
(330.8)
2.08
(52.8)
E
A
B
ø.47
thru support hole
(ø12.0)
METRIC METRIC
4.94
(125.4)
3.33
(84.6)
2.61
(66.4)
0.4
(10.2)
Compensator adjusting knob
(CW rotation increases
pressure setting)
Outlet port / Inlet port
opposiete sides
Inches (millimeters)
