54 VPV Vane Pump
VPV 45/63/80 to an ‘F’ Gear pump (continued)
,y
BOSCH
|
ø4.92
(ø124.97)
0.36
(9.25)
2.70
(68.5)
Pump
centerline
0.41
(10.5)
ø5.00
(ø126.98)
0.31
(8.0)
2.20
(56.0)
0.49
(12.45)
DETAIL SAE1
DETAIL METRIC1
VIEW B-B
(SH.1 @ H-2)
VIEW A-A
(SH.1 @ N-4)
2.95
(75.0)
3.73
(94.7)
2.04
(51.7)
1.19
(30.18)
6.89
(174.9)
max.
0.59
(15.09)
1.16
(29.36)
2.31
(58.72)
5.36
(136.2)
See detail "SAE1/METRIC1"
"SAE" 7/16-14UNC-2B TH'D
X
1.14
deep typ
"METRIC" M12 X 1.75-6H TH'D (29.0)
4 holes
Support point
"SAE" 3/8"-16UNC-2B TH'D
X
0.59
deep
"METRIC" M10 X 1.5 TH'D (15.0)
Support (Lift) point
"SAE & METRIC" M10 X 1.5-6H TH'D
X
0.44
deep
(11.2)
SAE "F" gear pump
Pressure outlet port
std. S.A.E. 1-1/4" pad
ø1.25
(ø31.8)
Optional volume control
(CW rotation reduces flow)
Inches (millimeters)
Gear pump Total Weight
Theoretical
Dimension
Gear Pump Port Sizes (Vane Pump &
Displacement A B C D E F Gear Pump)
in
3
/rev in. in. in. in. in. in. Inlet Outlet lbs.
(cc/rev) (mm) (mm) (mm) (mm) (mm) (mm) (Kg)
0.24 1.571 3.346 13.30 15.08 13.56 15.35 9/16-18 UNF 9/16-18 UNF 135
(4) (39.9) (85.0) (337.8) (383.2) (344.6) (390.0) (61.2)
0.34 1.618 3.445 13.35 15.19 13.62 15.45 9/16-18 UNF 9/16-18 UNF 135.2
(5.5) (41.1) (87.5) (339.1) (385.7) (345.9) (392.5) (61.3)
0.49 1.697 3.606 13.43 15.34 13.70 15.61 7/8-14 UNF 7/8-14 UNF 135.4
(8) (43.2) (91.6) (341.1) (389.7) (347.9) (396.5) (61.4)
0.67 1.850 3.803 13.58 15.49 13.85 15.76 1-1/16-12 UN 7/8-14 UNF 135.6
(11) (47.0) (96.6) (344.9) (393.4) (351.7) (400.2) (61.5)
0.85 1.870 4.0 13.60 15.69 13.87 15.96 1-1/16-12 UN 7/8-14 UNF 135.8
(14) (47.5) (101.6) (345.4) (398.5) (352.2) (405.3) (61.6)
0.98 1.870 4.134 13.6 15.86 13.87 16.13 1-1/16-12 UN 7/8-14 UNF 135.9
(16) (47.6) (105.0) (345.6) (403.0) (352.4) (409.8) (61.6)
1.16 1.870 4.330 13.6 16.06 13.86 16.33 1-1/16-12 UN 7/8-14 UNF 136.1
(19) (47.5) (110.0) (345.5) (408.0) (352.3) (414.8) (61.7)
1.37 2.169 4.543 13.90 16.27 14.17 16.54 1-1/16-12 UN 7/8-14 UNF 136.4
(22.5) (55.1) (115.4) (353.12) (413.4) (359.9) (420.2) (61.9)
