Bosch VPV 16 User Manual

VPV Vane Pump 57
VPV 45/63/80 to an ‘G’ Gear pump (continued)
,y
BOSCH
|
ø4.92
(ø124.97)
0.36
(9.25)
2.70
(68.5)
Pump
centerline
0.41
(10.5)
ø5.00
(ø126.98)
0.31
(8.0)
2.20
(56.0)
0.49
(12.45)
DETAIL SAE1
DETAIL METRIC1
VIEW B-B
(SH.1 @ H-2)
VIEW A-A
(SH.1 @ N-4)
2.95
(75.0)
5.88
(149.7)
2.04
(51.7)
1.19
(30.18)
6.89
(174.9)
max.
0.59
(15.09)
1.16
(29.36)
2.31
(58.72)
5.36
(136.2)
See detail "SAE1/METRIC1"
"SAE" 7/16-14UNC-2B TH'D
X
1.14
deep typ
"METRIC" M12 X 1.75-6H TH'D (29.0)
4 holes
Support (Lift) point
"SAE & METRIC" M10 X 1.5-6H TH'D
X
0.44
deep
(11.2)
SAE "G" gear pump
Pressure outlet port
std. S.A.E. 1-1/4" pad
ø1.25
(ø31.8)
Optional volume control
(CW rotation reduces flow)
Inches (millimeters)
Gear pump Total Weight
Theoretical
Dimension
Gear Pump Port Sizes (Vane Pump &
Displacement A B C D Gear Pump)
in
3
/rev in. in. in. in. Inlet Outlet lbs.
(cc/rev) (mm) (mm) (mm) (mm) (Kg)
1.37 2.40 5.07 14.6 17.26 1 " S.A.E. 3/4" S.A.E. 271.4
(22.5) (61.0) (128.5) (370.8) (438.6) 4 bolt 4 bolt (123.1)
1.71 2.48 5.26 14.68 17.45 1 " S.A.E. 3/4" S.A.E. 271.8
(28) (63.0) (133.7) (372.8) (443.2) 4 bolt 4 bolt (123.3)
1.95 2.54 5.40 14.74 17.59 1 " S.A.E. 3/4" S.A.E. 272.3
(32) (64.5) (137.2) (374.4) (446.8) 4 bolt 4 bolt (123.5)
2.32 2.62 5.62 14.82 17.81 1 " S.A.E. 3/4" S.A.E. 272.6
(38) (66.5) (142.6) (376.4) (452.3) 4 bolt 4 bolt (123.6)
2.75 2.74 5.87 14.94 18.06 1 " S.A.E. 3/4" S.A.E. 273.1
(45) (69.5) (149.2) (379.4) (458.7) 4 bolt 4 bolt (123.9)
3.42 2.95 6.31 15.15 18.5 1 " S.A.E. 3/4" S.A.E. 274.1
(56) (75.2) (160.2) (384.8) (469.9) 4 bolt 4 bolt (124.3)
