VPV Vane Pump 5
Specifications
General VPV 100 VPV 130 VPV 164
Displacement (Nominal) 6.1 in
3
/rev (100 cm
3
/rev) 7.9 in
3
/rev (130 cm
3
rev) 10.0 in
3
/rev (164 cm
3
/rev)
Displacement (Actual) 6.0 in
3
/rev (99 cm
3
/rev) 8.0 in
3
/rev (131 cm
3
rev) 10.0 in
3
/rev (164 cm
3
/rev)
Flow at 1750 RPM
1
45.4 GPM (171.8 L/min) 59.85 GPM (226.5 L/min) 75.76 GPM (286.7 L/min)
Maximum continuous pressure 3000 psi (210 bar) 3000 psi (210 bar)
Pressure compensating Two stage 350-3000 psi (24-210 bar) 350-3000 psi (24-210 bar)
Maximum transient spike pressure 4000 psi (280 bar) 4000 psi (280 bar)
Maximum case pressure 10 psi (0.7 bar)
Speed range 1150-1800 RPM
Direction of rotation (viewed from shaft end) Right hand (clockwise)
Case drain flow 1000 psi (70 bar) 1.5 GPM (5.7 L/min) 1.6 GPM (6.0 L/min) 1.7 GPM (6.4 L/min)
while compensating 2000 psi (140 bar) 2.0 GPM (7.6 L/min) 2.2 GPM (8.3 L/min) 2.3 GPM (8.7 L/min)
@1800 RPM 3000 psi (210 bar) 2.5 GPM (9.5 L/min) 3.0 GPM (11.3 L/min) 3.1 GPM (11.7 L/min)
Maximum inlet vacuum at sea level 6 in. HG (152 mm HG)
Mounting
2
- SAE 2-bolt flange (ISO 3019/1) S.A.E. ‘D’, 2-bolt flange
Mounting Position Unrestricted
Inlet 2 1/2” S.A.E.
Outlet 1 1/2” S.A.E.
Port sizes Case drain S.A.E. = #8 S.A.E.
Remote control (optional) #4 S.A.E.
Drive Pump to be connected to prime mover by means of a flexible coupling that is aligned
to a maximum of .006” (.152mm) total indicator reading. No overhung or side loads
permitted. Alignments greater than .006” indicator reading could cause increased
noise and vibration as well as premature shaft seal wear resulting in leakage.
Fluid recommendations A premium quality hydraulic oil with anti-wear additives is required*. Refer to publica-
tion S-106 “Petroleum Hydraulic Fluids” for a list of fluids which meet or exceed the
necessary lubrication requirements. Consult factory for use with water base fire
resistant fluids. *Such as Mobil DTE-26, or similar, for pressures over 2000 psi.
Minimum 150 SUS (32 cSt)
Fluid viscosity at Maximum 1000 SUS (216 cSt)
operating temperature Optimum 200-300 SUS (42-65 cSt)
Maximum start-up 4000 SUS (864 cSt)
Fluid temperature Normal inlet fluid temperature should not exceed 140°F (60° C). Always select a fluid
for optimum viscosity at operating temperature. Consult factory for applications assis-
tance when inlet fluid temperatures over 140° F (60° C) are expected.
Seals Fluorocarbon Standard
Filtration Fluid cleanliness per ISO/DIS 4406 should be 18/15 or better for pressures of 2000 psi or
less. For continuous operating pressures of 2000 to 3000 psi, fluid cleanliness should be
17/13 or better.
Response time Full flow to 20-50 ms
(circuit dependent) minimum flow
Recovery time Minimum flow 250-500 ms – two stage compensator
(circuit dependent) to full flow
Weight Single stage 240 lbs. (109 kg)
Two stage 248 lbs. (112.7 kg)
1
Flows are actual. Volumetric efficiencies shown in technical data taken into account.
2
Metric
4-bolt flange
available
(ISO 3019/2)
available. Please consult factory.
