Bosch VPV 16 - Page 60

VPV Vane Pump 59
VPV 45/63/80 to VPV 45/63/80 (continued)
BOSCH
OUT
IN
,y
z
BOSCH
ø4.92
(ø124.97)
.36
(9.25)
.41
(10.5)
2.70
(68.5)
Detail SAE1
Detail METRIC1
View B-B
(SH.1 @ H-2)
View A-A
(SH.1 @ P-2)
2.95
(75.0)
5.88
(149.4)
.59
(15.09)
1.19
(30.18)
5.36
(136.2)
11.12
(282.4)
15.48
(393.1)
18.80
(477.6)
Support (Lift) point
"SAE & METRIC"
M10 X 1.5-6H TH'D X
.44
deep typ
(11.2)
Support point
"SAE" 5/8"-11 UNC-2b TH'D
X
1.30 deep typ
"METRIC" M16 x 2-6H TH'D
(33.0)
Optional volume control
(CW rotation reduces flow)
Outlet port
Std. S.A.E. 1-1/4" pad
ø1.25
typ
(ø31.8)
6.89
(174.9)
max.
2.04
(51.7)
2.31
(58.72)
1.16
(29.36)
"SAE" 7/16"-14UNC-2B TH'D
X
1.14
deep typ
"METRIC" M12 X 1.75-6H TH'D
(29.0)
4 holes
See detail "SAE1/METRIC1"
ø5.00
(ø126.98)
.31
(8.0)
.49
(12.45)
2.20
(56.0)
Inches (millimeters)
