VPV Vane Pump 69
VPV 100/130/164 to VPV 25/32 (continued)

18.96
(481.6)
20.43
(519.0)
Inlet port
7.33
(186.2)
4.65
(118.1)
6.63
(168.6)
Remote control
Optional 2-stage
compensator
Shock clipper drain
2 stage compensator
adjusting knob
(CW rotation increases
pressure setting)
2 stage compensator
9.36
(237.8)
8.67
(220.2)
5.77
(146.6)
4.88
(123.9)
1.08
(27.5)
View A-A
Inches (millimeters)
