Bosch VPV 16 - Page 72

VPV Vane Pump 71
VPV 100/130/164 to VPV 45/63/80 (continued)
{
|
|
{
BOSCH
OUT
IN
ø6.30
(ø160.0)
.36
(9.25)
.40
(10.1)
3.62
(92.1)
ø6.00
(ø152.4)
.32
(8.1)
0.49
(12.45)
2.96
(75.1)
Detail SAE1
Detail METRIC1
View A-A
(SH.1 @ P-1)
4.15
(105.5)
2.95
(75.0)
5.88
(149.4)
2 places
5.96
(151.4)
5.91
(150.0)
8.41
(213.7)
9.24
(234.7)
13.03
(330.8)
View B-B
(SH.1 @ G-1)
1.41
(35.7)
.70
(17.9)
6.20
(157.4)
13.48
(342.4)
17.84
(453.1)
21.17
(537.6)
“SAE” 7/16”-14 UNC-2B TH’D typ
“METRIC” M12 x 1.75-6H TH’D typ
Optional volume control
(CW rotation reduces flow)
6.89
(174.9)
max.
1.86
(47.3)
2.75
(69.9)
1.37
(34.9)
“SAE” 1/2”-13UNC-2B TH’D X 1.10
deep
“METRIC” M12 X 1.75-6H TH’D (28.0)
See detail
“SAE1/METRIC1”
Outlet port
Std. “SAE” 1 1/4” pad
ø1.25
(ø31.8)
Support (Lift) point
“SAE & METRIC”
M10 X 1.5-6H TH’D
X
.43
deep
(11.0)
Support (Lift) point
“SAE & METRIC”
M10 X 1.5-6H TH’D
X
.43
deep
(11.0)
Support point
“SAE” 5/8”-11UNC-2B TH’D
1.30
deep
(33.0)
“METRIC” M16 X 2-6H TH’D
1.30
deep
(33.0)
8.57
(217.7)
max.
6.61
(168.0)
Outlet port
Std. S.A.E. 1-1/2” pad
ø1.46
(ø37.1)
1.19
(30.18)
59
(15.09)
2.31
(58.72)
1.16
(29.36)
Inches (millimeters)
