76 VPV Vane Pump
VPV 45/63/80 to an ‘F’ Gear pump (continued)
{
|
ø6.30
(ø160.0)
.36
(9.25)
.40
(10.1)
3.62
(92.1)
ø6.00
(ø152.4)
.32
(8.1)
0.49
(12.45)
2.96
(75.1)
Detail SAE1
Detail METRIC1
View A-A
(SH.1 @ P-2)
4.15
(105.5)
7.65
(194.2)
7.27
(184.7)
8.41
(213.7)
9.24
(234.7)
16.08
(408.5)
View B-B
(SH.1 @ G-1)
1.41
(35.7)
.70
(17.9)
6.20
(157.4)
13.18
(334.9)
Support point
"SAE" 3/8"-16 UNC-2B TH'D X .87
deep
(22.0)
"METRIC" M10 x 1.5-6H TH'D X .87
deep
(22.0)
Optional volume control
(CW rotation reduces flow)
Outlet port
Std. S.A.E. 1-1/2" pad
ø1.46
(ø37.1)
1.86
(47.3)
2.75
(69.9)
1.37
(34.9)
"SAE" 1/2"-13UNC-2B TH'D X 1.10
deep
"METRIC" M12 X 1.75-6H TH'D (28.0)
See detail
"SAE1/METRIC1"
SAE "G" gear pump
Support (Lift) point
“SAE & METRIC”
M10 X 1.5-6H TH’D
X
.43
deep
(11.0)
8.57
(217.7)
max.
Inches (millimeters)
Gear pump Total Weight
Theoretical
Dimension
Gear Pump Port Sizes (Vane Pump &
Displacement A B C D Gear Pump)
in
3
/rev in. in. in. in. Inlet Outlet lbs.
(cc/rev) (mm) (mm) (mm) (mm) (Kg)
1.37 2.40 5.07 17.0 19.60 1 " S.A.E. 3/4" S.A.E. 271.4
(22.5) (61.0) (128.5) (430.8) (498.4) 4 bolt 4 bolt (123.1)
1.71 2.48 5.26 17.04 19.80 1 " S.A.E. 3/4" S.A.E. 271.8
(28) (63.0) (133.7) (432.8) (503.0) 4 bolt 4 bolt (123.3)
1.95 2.54 5.40 17.10 19.90 1 " S.A.E. 3/4" S.A.E. 272.3
(32) (64.5) (137.2) (434.4) (506.6) 4 bolt 4 bolt (123.5)
2.32 2.62 5.62 17.18 20.16 1 " S.A.E. 3/4" S.A.E. 272.6
(38) (66.5) (142.6) (436.4) (512.1) 4 bolt 4 bolt (123.6)
2.75 2.74 5.87 17.30 20.40 1 " S.A.E. 3/4" S.A.E. 273.1
(45) (69.5) (149.2) (439.4) (518.5) 4 bolt 4 bolt (123.9)
3.42 2.95 6.31 17.51 20.85 1 " S.A.E. 3/4" S.A.E. 274.1
(56) (75.2) (160.2) (444.8) (529.7) 4 bolt 4 bolt (124.3)
