8 VPV Vane Pump
Ordering Guide, cont.
Item No Code
13 Solenoid Operated Vent Two Press. Norm. (Normally vented)/Energize to Pressure
(cont.) ZA 115V N.V. w/DIN 43650 & quick connect (compression fitting) w/sentinel light
ZB 220V N.V. w/DIN 43650 & quick connect (compression fitting) w/sentinel light
ZC 12V N.V. w/DIN 43650 & quick connect (compression fitting) w/sentinel light
ZD 24V N.V. w/DIN 43650 & quick connect (compression fitting) w/sentinel light
ZE 115V N.V. w/flying leads
ZF 220V N.V. w/flying leads
ZG 12V N.V. w/flying leads
ZH 24V N.V. w/flying leads
Solenoid Operated Vented Norm. High (Normally closed)/Normally at Pressure/Energize to Vent
WA 115V N.C. w/DIN 43650 & quick connect (compression fitting) w/sentinel light
WB 220V N.C. w/DIN 43650 & quick connect (compression fitting) w/sentinel light
WC 12V N.C. w/DIN 43650 & quick connect (compression fitting) w/sentinel light
WD 24V N.C. w/DIN 43650 & quick connect (compression fitting) w/sentinel light
WE 115V N.C. w/flying leads
WF 220V N.C. w/flying leads
WG 12V N.C. w/flying leads
WH 24V N.C. w/flying leads
14 Accessories
S Special (Consult Factory)
Y Maximum delivery limiter
Z No other accessories
15 B01 Design Series
P1 Pump 1 of a quick combination unit (adapter kit & coupling required to create a combination-see page 81)
Item No Code
6 Principle of Operation
HY/Z Hydraulic Gear Pump
7 Size Range
F 4 cc to 22.5cc
8 Type of Construction
S11 Standard version
S21 Duo (low noise version)
9 Displacement
4 4 cc/rev = .244 cu in/rev
5.5 5.5 cc/rev = .335 cu in/rev
8 8 cc/rev = .488 cu in/rev
11 11 cc/rev = .671 cu in/rev
14 14 cc/rev = .854 cu in/rev
16 16 cc/rev = .976 cu in/rev
19 19 cc/rev = 1.159 cu in/rev
22.5 22.5 cc/rev = 1.372 cu in/rev
10 Direction of Rotation
R Right hand (clockwise)
11 Details
254 SAE “A” flange, 2 bolt, SAE keyed shaft
253 SAE “A” flange, 2 bolt, ANSI spline shaft, 9 T, 16/32 pitch
Gear Pump Guide
