Bose CineMateSERIES II - Connect the Interface Module

11
SYSTEM SETUP
TAB 5TAB 4TAB 6TAB 8TAB 7English TAB 3TAB 2
1. Insert the plug from the interface module
into the input connector on the back of the
Acoustimass module.
2. Continue with on the next page.
3
Connecting
the interface module
What you need to use:
Interface module
Acoustimass
®
module
Fastener screws
4
