Bose CineMateSERIES II - Connect Speakers to Acoustimass Module

9
SYSTEM SETUP
TAB 5TAB 4TAB 6TAB 8TAB 7English TAB 3TAB 2
1. Notice the two plugs at one end of the speaker
cable.
2. Separate the two plugs so each one reaches a
speaker.
2
Connecting the
speakers to the
Acoustimass
®
module
What you need to use:
Acoustimass
module
Speaker cable
CineMate
®
GS series II
Gemstone
®
speakers
OR
CineMate series II
speakers
