Bose L1 II User Manual

14
Main Part List
L1
®
Model II Power Stand Upper Housing (see Figure 5)
Item
Number
Description Bose
®
Part
Number
V
endor Part Numbe
r
Qty. Note
1 HOUSING, UPPER 298051 1467-7901+0 1
- I / O PANEL ASSY,
(ITEMS 2 TO 15 AND 32)
304130
304990
SVC-PS211+IOPAN
SVC-PS211+IOPANEU
1
1
US/CAN
EU/AUS
2 SWITCH, AC POWER,
ROCKER, 2P1T
304984 5200-4910+0 1 3
3 & 4 SCREW, M3X12, CSH, BK - 2901-3012+3000 2 4
5 SCREW, B-TITE, FLAT-CS,
M3X10, BZ
- 2951-3010+3000 2 4
6 I/O PANEL COVER, US/CAN
I/O PANEL COVER, EU/AUS
298072
311082
1467-8001+0
1467-8002+0
1
1
7 SCREW, M4X12, PH, BK - 2900-4012+3000 6 4
8 LED LIGHTPIPE #2 298381 3717-4306+0 1
9 LED LIGHTPIPE #1 298380 3717-4206+0 1
10 AC POWER SOCKET 304131 2113-1144+0 1 3
11 BRACKET, AC INLET 298383 4135-6971+0 1
12 AC PRIMARY PCB ASSY 304983 SVC-PS211+PRI 1 2,3
13 I/O-DSP PCB ASSY 298612 or
355475-001s
SVC-PS211+DSP 1 2
14 SHIELD, COVER - 4135-6841+0 1
15 SCREW, B-TITE, BIND, M3X8 - 2954-3006+0000 8 4
- AMP/SMPS ASSY, CONSISTS
OF ITEMS 16 TO 31
304985
304987
SVC-PS211+AMPASY
SVC-PS211+AMPASYEU
1 1, 2
16 SCREW, 3*8, 5.2MM, BK, ZNC - 2930-3008+3000 2 4
17 WASHER, ID 3.3, OD 8, T=0.5 - 2600-3005+0640 2 4
18 HANDLE 298054 4155-2221+0 1
19 SCREW, D3X5, B-TITE, YZN - 2954-3005+0000 2 4
20 FAN GRILLE 298058 4135-6801+0 1
21 SCREW, MACHINE, FLAT-CS,
M3X6, BZ
- 2901-3006+3000 3 4
22 PCB BRACKET 298067 4135-6721+0 1
23 FAN BRACKET - 4135-7131+0 1 4
24 SCREW, M4X6, P/M, BLK - 2900-4006+3000 4 4
25 FAN, DC, 12V, 5500 RPM See service
bulletin
296133-B1
- 2 3
26 SCREW, MACHINE, M3X12,
B/H, BLACK, ZINC
- 2900-3010+3000 4 4
27 PCB SHIELD SHEET - 4155-2281+0 1
28 MICA INSULATING SHEET 304986 3100-6751+1 2
29 HEAT SINK, PCB BRACKET 298073 5400-9811+0 2
30 SMPS/PWR AMP PCB ASSY
US/CANADA
EURO/AUS
358960-111S
358961-211S
PCB-PS211-+AMP
PCB-PS211-+AMPEU
2
2
31 SCREW, MACHINE, M3X5,
BH, Y-ZINC
- 2904-3005+0000 14 4
32 KNOB, VR 298382 2447-4011+0 1
