16
Main Part List
L1
®
Model II Power Stand Cavity and Leg Assembly (see Figure 6)
Item
Number
Description Bose
Part
Number
Vendor Part Number Qty. Note
LEG ASSEMBLY, INCLUDES: 304129 SVC-PS211+LEGASY 1
1 LEG-1 - 4135-6821+0 2 4
2 FOOT - 4157-1191+0 4 4
3 WASHER, METAL, M4X0.8X10 - 2600-4008+1003 4 4
4 SCREW, M4X12, PH, BK - 2900-4012+3000 4 4
5 LEG-2 - 4135-6831+0 2 4
6 LOWER LEG BEARING - 4155-2271+0 4 4
7 SCREW, MACHINE, FLAT-CS,
M3X6, BZ
- 2901-3006+3000 16 4
8 SCREW, MACHINE, 4*6,
6.8MM, BK, CR HD
- 2901-4006+9000 16 4
9 SCREW, MACHINE, FLAT-CS,
M4X12, BZ
- 2901-4012+3000 2 4
10 BOTTOM COVER - 1406-1701+0 1 4
11 BEARING SUPPORT - 4135-6731+0 4 4
12 UPPER LEG BEARING - 4155-2261+0 4 4
13 SCREW, FLAT-CS, M3X5MM,
BZ
- 2901-3005+3000 12 4
14 CROSS BEAM - 4135-6781+0 2 4
15 SCREW, M4X6, P/M, BLK - 2900-4006+3000 4 4
16 LINE ARRAY CONNECTOR /
CABLE HARNESS
- 7012-8500+0 1 4
17 CAVITY, LINE ARRAY - 4135-6811+0 1 4
18 SCREW, MACHINE, 4*5, 6MM,
BLK, CROSS RCS
- 2901-4005+3000 4 4
19 LINKAGE MOTHER PLATE - 4135-6711+0 1 4
20 GUIDE MOTHER PLATE - 4155-2231+0 1 4
21 SCREW, MACH, PAN, M3X8,
BZ
- 2900-3008+3000 6 4
22 GUIDE SHAFT, BLACK - 4135-6891+0 2 4
23 CAVITY STOP 298069 4155-2241+2 1 4
24 BEARING PLATE #1 - 4135-6761+0 2 4
25 SCREW, FLAT-CS, M6X14, BZ - 2901-6014+3000 8 4
26 BEARING PLATE #2 - 4135-6771+0 2 4
27 FRONT LINK - 4135-6741+0 2 4
28 REAR LINK - 4135-6751+0 2 4
29 LINK BEARING - 4155-2251+0 8 4
30 LINK BEARING WASHER - 2608-8508+1601 8 4
31 METAL WASHER - 2600-6005+1003 8 4
32 SPRING WASHER - 2607-6212+1200 8 4
33 NUT, HEX, 6MMX5.0T, BK, ZN - 2640-6050+1003 8 4
34 EMI GASKET, SHIELDING - 4149-1111+0 4 4
16
17
PS2 CAVITY ASSEMBLY
INCLUDES:
CONN, CABLE HARNESS
CAVITY, ALUMINUM
304128
-
-
-
7012-8500+0
4135-6811+0
1
4
4
