18
Main Part List
L1
®
Model II Line Array (see Figure 7)
Item
Number
Description Bose
Part
Number
Vendor Part
Number
Qty. Note
- UPPER GRILLE ASSEMBLY;
CONSISTS OF ITEMS 3, 25, & 26
304988 SVC-
L211+GRILLUP
1
- LOWER GRILLE ASSEMBLY;
CONSISTS OF ITEMS 3 AND 7
304989 SVC-
L211+GRILLOW
1
1 MS SCREW, M3X12, CSH.BK - 2901-3012+3000 8 4
2 SCREW, B-TITE, FLAT-CS, M3X10 - 2951-3010+3000 8 4
3 GASKET, GRILLE - 4149-1261+0 4
4 GASKET, BAFFLE SCREW - 4149-1181+0 24
5 BAFFLE, DRIVER - 4155-2291+0 4
6 GASKET, BAFFLE TOP - 4149-1191+0 2
7 GRILLE, LOWER SECTION, NO
LOGO
298024-02 4135-6851+1 1
8 SCREW, 3.5X10MM, B-TITE, BL
- 2954-3510+3000 53 4
9 WASHER, RUBBER, M4X1.5X6.5 - 2603-4015+0651 48
10 BRACKET, END CAP #4 298029 4135-6861+0 1
11 SCREW, M4X8, TTP/B, YW, ZN - 2920-4007+0000 1 4
12 WASHER, SPRING, M4X1X7, YZ - 2607-4010+0700 1 4
13 WASHER, EXT TOOTH,
M4X0.8X8.5
- 2605-4008+0850 1 4
14 SHEET, AIRPROOF - 4155-2701+0 1
15 SCREW, 3.5X10MM, B-TITE, BLK - 2954-3510+3000 53 4
16 SCREW, M3X8, C’SINK, FLT HD - 2951-3008+3000 1 4
17 EVA GASKET, BAFFLE - 4149-1121+0 8
18 WIRE, 4P, P5.08, #20, UL1007 - 7012-8520+0 1
19 HOUSING, LOWER SECTION - 1406-1901+0 1
20 SPONGE, AIRPROOF - 4149-1301+0 2
21 SCR, MACH, 4*15, 6.8MM, BK/C
HD
- 2900-4015+3000 1 4
22 WASHER, METAL, M4X0.8X10, BZ - 2600-4008+1003 1 4
23 2.75” DRIVER, GR, 6 OHM 303836 SVC-WF+BSPAL2 24
24 SCREW, MACH, M3.5X8, 6.7MM - 2940-3508+3000 96 4
25 GRILLE, UPPER SECTION,
NO LOGO
298024-01 4135-6852+1 1
26 BOSE LOGO 303709 2150-7012+0 1
27 WIRE, 4P, P5.08, #20, UL1007 - 7012-8530+0 1
28 HOUSING, UPPER SECTION - 1406-1801+0 1
29 SCREW, MACH, OVAL-CS, M6X20 - 2902-6020+3000 2 4
30 BAYONET, LINE SOURCE 264001 8901-4270-0 1
