31
Electrical Part List
Input/Output PCB Assembly
Inductors
Reference
Designator
Description Vendor Part
Number
Note
L101 FERRITE BEAD, 125 OHM, SMD, ACB453215 1802-0630 4
L102 FERRITE BEAD, 125 OHM, SMD, ACB453215 1802-0630 4
L104 FERRITE BEAD, 125 OHM, SMD, ACB453215 1802-0630 4
L105 FERRITE BEAD, 125 OHM, SMD, ACB453215 1802-0630 4
L106 FERRITE BEAD, 125 OHM, SMD, ACB453215 1802-0630 4
L107 FERRITE BEAD, 125 OHM, SMD, ACB453215 1802-0630 4
L108 FERRITE BEAD, 125 OHM, SMD, ACB453215 1802-0630 4
L109 22uH, 20%, 8.1X8, B1000AS-220M=P3, SMD,
TOKO
1803-0103 4
L110 FERRITE BEAD, 125 OHM, SMD, ACB453215 1802-0630 4
L111 FERRITE BEAD, 125 OHM, SMD, ACB453215 1802-0630 4
L112 22uH, 20%, 8.1X8, B1000AS-220M=P3, SMD,
TOKO
1803-0103 4
L113 FERRITE BEAD, 125 OHM, SMD, ACB453215 1802-0630 4
L116 FERRITE BEAD, 125 OHM, SMD, ACB453215 1802-0630 4
L117 FERRITE BEAD, 125 OHM, SMD, ACB453215 1802-0630 4
L302 FERRITE BEAD, 125 OHM, SMD, ACB453215 1802-0630 4
Diodes
Reference
Designator
Description Vendor Part
Number
Note
D100 SCHOTTKY, 40V, 3A, ST, PS3L40S, DO-214AB,
SMD, ST
480L-40S0 4
D101 BAV99, SOT23, PHILIPS 4840-8970 4
D102 BAV99, SOT23, PHILIPS 4840-8970 4
D103 BAV99, SOT23, PHILIPS 4840-8970 4
D104 SCHOTTKY, 40V, 3A, ST, PS3L40S, DO-214AB,
SMD, ST
480L-40S0 4
D105 1SS355TE-17, ROHM 4840-1660 4
D106 1SS355TE-17, ROHM 4840-1660 4
D107 1SS355TE-17, ROHM 4840-1660 4
D108 1SS355TE-17, ROHM 4840-1660 4
D110 BAV99, SOT23, PHILIPS 4840-8970 4
D114 BAV99, SOT23, PHILIPS 4840-8970 4
D115 BAV99, SOT23, PHILIPS 4840-8970 4
D118 LOW CURRENT SMD LED, RED, 2mA 3700-7829 4
D119 LED, SMD, 3.2X2.4X2.4, RED 3700-7840 4
D120 LED, SMD, 3.2X2.4X2.4, RED 3700-7840 4
D121 LED, SMD, 3.2X2.4X2.4, RED 3700-7840 4
D122 LED, SMD, 3.2X2.4X2.4, RED 3700-7840 4
D123 LED, SMD, 3.2X2.4X2.4, BLUE 3700-7840 4
D124 LED, SMD, 3.2X2.4X2.4, BLUE 3700-7840 4
D125 LED, SMD, 3.2X2.4X2.4, GREEN 3700-7840 4
D126 LED, SMD, 3.2X2.4X2.4, GREEN 3700-7840 4
To Next Page
