Appendix
Function Table
Function PM8500 PM8500N Front Panel ControlSpace
Designer software
ESPLink Card
Set input sensitivity (dBu) X X X X
Set input gain (dB) X X X X
Set input mute X X X X
View input level (dB) X X X X
Set output attenuation (dB) X X X X
Set output mute X X X X
View output gain (dB) X X X X
View output voltage (V) X X X X
Load Bose
®
speaker EQ preset X X X X
View Bose speaker EQ X X X X
Load speaker array EQ X X X X
Adjust delay X X X X
Adjust limiting X X X X
Modify output configuration X X X X
Modify input routing X X X X
Enter/exit standby mode X X X X
View alarm log X X X X
Clear alarm X X X X
Erase alarm log X X X X
Set DHCP or Fixed IP network address X X X X
Lock front panel X X X X
Set front panel combination X X X X
Adjust display contrast X X X X
Restore factory presets X X X X
View firmware version X X X X
Update firmware version X X X X
Update speaker EQ files X X X X
Adjust/view input channel 5-Band PEQ X X X
Adjust/view advanced parameters for Array EQ X X X
Use of signal generator X X X
Adjust/view Bandpass Filters X X X
Adjust/view advanced parameters for Speaker EQ X X X
Use of Limiter Meters X X X
Use of Link Groups X X X
Per channel fault and limit indicators X X X
Set input type (analog vs digital) X X X X X
Setup of alarm conditions X X X
Measure/save/compare loudspeaker impedances X X X
Use of PowerMatch™ ESPLink Card X X X X X
Local Monitor Mode X X X
Network Monitor Mode X X
Configure and monitor multiple PM8500 amplifiers X X
Backup/restore amplifier configuration state X X X

Bose PowerMatch PM8500 Specifications

General

Efficiency	75 %
Amplifier class	D
Audio input channels	8 channels
Audio output channels	8.0 channels
Peak power per channel	500 W
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.1 %
USB port type	USB Type-B
Ethernet LAN data rates	100 Mbit/s
Ethernet LAN (RJ-45) ports	1
Speakers connectivity type	-
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Purpose	Performance/stage
Cooling type	Active
On/off switch	Yes
Product color	Black
Connectivity technology	Wired
Package weight	15700 g
Operating temperature (T-T)	0 - 40 °C
LED indicators	Fault

Weight and Dimensions

Depth	525 mm
Width	483 mm
Height	88 mm
Weight	12900 g
